Product Dimensions
Dimensions Table
Size | Metric Conversion | Q | L1 | L2 | L3 |
---|---|---|---|---|---|
1/2" | 15mm | 10 | 76 | 44.5 | 88 |
3/4" | 20mm | 10 | 85 | 43.5 | 88 |
Features:
90° Open/close operation.
Fitted with PTFE seals.
Fitted with union tail for use with a hose.
Size | Metric Conversion | Q | L1 | L2 | L3 |
---|---|---|---|---|---|
1/2" | 15mm | 10 | 76 | 44.5 | 88 |
3/4" | 20mm | 10 | 85 | 43.5 | 88 |
Maximum Working Pressure:
Up to 12 BAR
Temperature Rating:
0°C – 80°C
Suitable Applications:
Water, Oil, Gas
Material |
---|
Nickel Plated Brass |
PTFE Seals |
Steel Handle |
