FIG 587 - Delcop Coupler CxMI
Features
- High quality brass tapered hex nipple fitting. Made in accordance with ISO R thread standard (BSP tapered thread) and acid cleaned to ensure no swarf or contaminants.
Dimensions
| Code | Size mm | G | L | L1 |
|---|---|---|---|---|
| 562/0015 | 15 | ½†| 25.5 | 10.5 |
| 562/0020 | 20 | ¾†| 29 | 12 |
| 562/0025 | 25 | 1†| 31.5 | 13 |
| 562/0040 | 40 | 1½†| 39 | 16.5 |
| 562/0050 | 50 | 2†| 45 | 19 |
- Maximum working pressure
- 290PSI (20 Bar)
- Temperature rating
- 0°C to 120°C
- Suitable applications
- Water, Oil
Construction table
| Description | Material |
|---|---|
| Body | Hot forged brass |
| Manufactured according to EN1254-4 | |
| Fastening threads conform to ISO 228/1 |
