Features:
Fabricated as per ISO 9001 and can be utilized for Domestic and Commercial pipes, mechanical applications, rural prerequisites and warming, sterile, pneumatic frameworks, waterworks, high temp water administrations, condensate lines is appropriate with each non-forceful liquid.

[cs_pressure_conversion_calc title='My Pressure Conversion' text_color='#000000' background_color='#FFFFFF' header_color='#315aa2' header_text_color='#FFFFFF' border_color='#e1e0e0']

Product Dimensions

Dimensions Table

Size mmABCDEFGLWST
50851623012.765507421022032
65981743012.765507451022047
801041813012.765507451022065
1001232003015.990709.5521226090
1251362133019.190709.55414260111
1501482253019.190709.55614260145
2001862603822.212510211.56017358193
2502122923828.612510211.56622358241
3002513373831.812510211.57724358292

Technical Data

Maximum Working Pressure:
Up to 16 BAR

Suitable Applications:
Water, Oil, Gas



Construction Table

DescriptionMaterial
BodyCast Iron
SeatNBR. EPDM
Lower StemC45
DiscDuctile Iron
Upper StemC45
BushingPTFE
O-RingNBR. EPDM
LeverMalleable Cast Iron
Bolt & NutCarbon Steel
Locking PlateCarbon Steel
ScrewCarbon Steel
