Product Dimensions
Dimensions Table
Size | Metric Conversion | DN | L | L1 | H |
---|---|---|---|---|---|
1/2" | 15mm | 15 | 125 | 61 | 70 |
3/4" | 20mm | 20 | 140 | 68 | 85 |
1" | 25mm | 25 | 155 | 81 | 100 |
1 1/4" | 32mm | 32 | 175 | 90 | 120 |
1 1/2" | 40mm | 40 | 200 | 104 | 130 |
2" | 50mm | 50 | 205 | 124 | 145 |
Features:
Fitted with large ball so that the hole in the ball equates with the bore in the pipeline.
Full six thread connections tapered to BSP—21 taper.
Fitted with PTFE seals.
Material:
Nylon Body
PTFE Gland Packing
Iron ball and stem
Steel Handle
Size | Metric Conversion | DN | L | L1 | H |
---|---|---|---|---|---|
1/2" | 15mm | 15 | 125 | 61 | 70 |
3/4" | 20mm | 20 | 140 | 68 | 85 |
1" | 25mm | 25 | 155 | 81 | 100 |
1 1/4" | 32mm | 32 | 175 | 90 | 120 |
1 1/2" | 40mm | 40 | 200 | 104 | 130 |
2" | 50mm | 50 | 205 | 124 | 145 |
Maximum Working Pressure:
Up to 16 BAR
Temperature Rating:
0°C – 80°C
Suitable Applications:
Water, Oil
Description | Material |
---|---|
Handle | Chrome plated plastic coated |
Nut | Chrome plated |
Spring Washer | Steel |
Stem | Iron |
O-Rings | NBR |
Seat | PTFE |
Ball | Iron |
Body | Nylon |
